- Description
Main Features:
Turbine pump / direct drive coupling / Couplings Drive is applicable to aboveground or underground LPG tank at high differential pressure.
Advantage:
An economical and high-efficient alternative to submersible pump.
Meeting multiple demands for LPG filling. Either aboveground or underground LPG tank at high differential pressure, the pump can fill gas in high flow rate for double nozzles LPG dispenser.
Continuous and high-intensitive use.
Easy and economical to use.
Technical Specification:
| Inlet | 1.5'' |
| Outlet | 1'' |
| Speed | 60Hz 3450RPM or 50Hz 2880RPM |
| Max. Working Pressure | 27.6bar(400PSI) |
| Max. Differential Pressure | 17.2bar(250PSI) |
| Max. /Min Temperature | -32°C-107°C |
| Power of Motor | 5.5Kw |
| Package Data | ||
| Model | Pump Only | Pump With Motor |
| Size: | 37.5×30×40mm | 95×45×60mm |
| Net Weight: | 29kg | 120kg |
| Gross eight: | 35kg | 140kg |
| Package: | 1pc/Wooden Case | |
LPG gas pumps produced by our factory are mainly used to convey a variety of volatile liquids and petroleum products such as LPG, two methyl ether, propane and so on. It is especially used in the loading and unloading vehicles of LPG, the filling of steel cylinders, and the feeding of the LPG station workshop.
LPG turbine pump for high differential pressure application using, for underground and aboveground tank application.
