Description

Characteristics
• FMC series PD rotary vane meters are single case, angle-type, rotary vane, positive displacement meters.
• Superior accuracy and metering for a wide range of products, such as, gasoline, kerosene, fuel oils etc..
• Compact, versatile design can be readily fit into nearly all installations.
• Low pressure drop meter results in low meter slippage and thus superior meter accuracy.
• Long service life, low friction ball bearings, fixed cam-type timing, and rugged construction give sustained accuracy and long time operation.

Rotary Vane Flow Meter are single case, angle-type,rotary vane,postitve displacement meters.
Superior accuracy and a wide range of products from gasoline to kerosene to fuel oils can be metered.
Compact,versatile design can be readily fit into nearly all installations.
Low pressure drop meter results in low meter slippage and thus superior meter accuracy.
Long service life,low friction ball bearings,fixed cam-type timing,and rugged construction give sustained accuraccy and long time operation.

Application includes: blenging,batching,dispengsing, inventoty control,and custody transfer of oils,solvents, chemicals,paints,fats and fertilizers

FMC - 50 FMC Series PD Rotary Vane Flow Meter
Meter with mechnical register, air eliminator and strainer
Size： 2 inch
Flow range:38-380L/min
Ma* pressure:10Bar/150PSI
Accuracy:±0.2%
Repeatability: ≤0.07%
dimension：59*34*57 cm
Net weight: 42KGS Gross weight: 57 KGS
pack in 1 wooden case

FMC - 80 FMC Series PD Rotary Vane Flow Meter
Meter with mechnical register, air eliminator and strainer
Size： 3 inch
Flow range:75-750L/min
Ma* pressure:10Bar/150PSI
Accuracy:±0.2%
Repeatability: ≤0.07%
dimension：70*40*58cm
Net weight: 56KGS Gross weight: 70 KGS
pack in 1 wooden case

FMC - 100 FMC Series PD Rotary Vane Flow Meter
Meter with mechnical register, air eliminator and strainer
Size： 4 inch
Flow range:150-1500L/min
Ma* pressure:10Bar/150PSI
Accuracy:±0.2%
Repeatability: ≤0.07%
dimension：83*46*65 cm
Net weight: 80 KGS Gross weight: 96 KGS
pack in 1 wooden case
